Derul Cable- High Strength Spreader Cable- Flexible Cable Manufacturer

Derul High Strength Spreader Cable

تخصيص

Basic structure	Conductor+Insulation+Jacket
Conductor	Plain Copper/ Tinned Copper
Insulation	EPR
Braid	Kevlar/ Plain Copper/ Tinned Copper
Jacket	PUR/TPE/PCP

مطلوب الان المنتج التالي

مقدمة

Detail Information

Conductor	Stranded Oxygen-Free Copper Wire(VDE0295 CLASS5)	Rated Voltage	0.6/1 kV
Insulation	Special Elastomer Insulation	Test Voltage	3500V/5min
Color Code	Black Number	Min. Bending Radius:
Fiber Optic	Single/Multi Mode Fiber Optic 4-24 Core	Fixed Installation	6 X Outer Diameter
Stranding	Stranded, with Strength Member Filled in the Middle/Side	Mobile Installation	10 X Outer Diameter
Inner Jacket	Oil/Wear Resistant PUR/NBR Jacket	Max. Tension	20N/mm²
Strength Member	Kevlar Fiber Braiding	Max. Traveling Speed	180m/min
Outer Jacket	Oil/Wear Resistant PUR Jacket	Working Temperature:
Jacket Color	Yellow/Black	Fixed Installation	-25℃-+70℃
Flame Retardant	IEC60332-1	Mobile Installation	-15℃-+70℃

A spreader cable, also known as a spreader bar or lifting beam, is an important component in lifting and rigging systems used for material handling in various industries. It plays a vital role in distributing the load and ensuring the stability and safety of the lifting operation. The spreader cable is often applied in cranes, hoists, and other lifting equipment to ensure the safe movement of heavy or awkwardly shaped loads. Derul makes its design and features to be contributed to load stability, safety, and efficiency, making them integral components in various industries where heavy lifting is a essential part of operations.

Also, the cable is suitable for large machinary, mobile hoist, spreader system, underground and surface mining, as well as mobile application under high load.

Type No.	Core No. & Section Area	Appx. Weight kg/m	Appx. Outer Diameter mm±10%	Max. Tension N
1	48x1.0(6x8x1.0)	1.40	28.7	2000
2	18x1.5(6x3x1.5)	0.75	19.5	3000
3	18x2.5(6x3x2.5)	1.15	25.4	3000
4	24x2.5(6x4x2.5)	1.50	31.0	3000
5	30x2.5(6x5x2.5)	1.60	32.5	4500
6	36x2.5(6x6x2.5)	2.05	36.5	4500
7	42x2.5(6x7x2.5)	2.25	39.0	5000
8	54x2.5(6x9x2.5)	2.80	45.0	6000
9	6x4x2.5+FO	1.60	32.5	4500
10	6x5x2.5+FO	2.05	36.5	4500
11	6x6x2.5+FO	2.25	39.0	5000
12	6x8x2.5+FO	2.80	45.0	6000

Like its similiar types known as NSHTOEU and NSHTOU, the cables are made under the DIN VDE 0295 Class 5 and IEC 60228 Class 5 standards, and are also up to the requirements of IEC60811-2-1 and IEC60332-1.

مزايا

Derul spreader cables are constructed adapting high-strength materials such as alloy steel to withstand the loads they are designed to lift. The choice of materials and construction methods of the cables ensures durability and reliability in various working conditions. For safety considerations, they are all made under industry standards and regulations. Also, some are designed for use in maritime settings, construction sites, or manufacturing facilities, addressing the unique requirements of each environment. Features such as lightweight construction, ergonomic designs, and user-friendly attachment points make them efficient use. In applications where exposure to harsh environments is common, spreader cables may be designed with corrosion-resistant coatings or materials to ensure long-term durability.

In summary, Derul spreader cable is :

Flexible, bend resistent
Tensile, tear resistent, stable performance
Good oil resistent, wear resistent, cold resistent, weather resistent, acid and alkali resistent, UV resistent, suitable for outdoor application.

القدرة على التخصيص

Whenever standards are not enough!

Considering different working conditions and equipment to be applied to, Derul's products are highly customized. The high customization of our cables can make sure that our products can best meet the demands in your practical application. We welcome you to send an inquiry with specific requirements to our professional sales, and we will provide a technical sheet with drawings of the cable and detailed specifications to you, and of course, a competitive quotation will be send to you soon after your confirmation on the technical sheet. This can lead to your successful and efficient purchasing.

You don't need to worry about the time cost of your customized purchasing. As the original manufacturer, we provide quick-response and "solution at once" services. Comparing to less-efficient communication about technical and quality issues with trading companies, we give our customers efficient feedback to every question raised from them, this is possible because of the close interconnection between our workshop, engineers and sales people.

التعليمات

Q: هل ديرول كيبل شركة مصنعة أم شركة تجارية؟

A: Derul Cable هي شركة تصنيع كابلات خاصة مقرها في شنغهاي.

Q: هل السعر قابل للتفاوض؟

A: نعم ، السعر قابل للتفاوض وفقا لكمية الشراء.

Q: ما هو موك العادي للكابل؟

A: أي كمية على ما يرام لشراء المنتج في المخزون. بالنسبة للمنتج الذي يجب تصنيعه بعد الطلب ، يكون موك عادة 100-200 متر لكل نوع.

Q: كيف يمكنني الحصول على عينات؟

A: بعد الدفع للتكلفة المحتملة بما في ذلك الشحن السريع وتأكيد أبعاد الكابل وهيكله ، سنقوم بترتيب العينة وإرسالها مباشرة إلى باب منزلك.

Q: هل تتوفر خدمة OEM أو ODM؟

A: تتوفر خدمات OEM و ODM. يمكنك تزويدنا بمتطلباتك وسنقوم بتقييمها للمضي قدما.

Q: ما هو وقت الإنتاج العادي؟
